The evolution of Passport® Monitoring has arrived – Mindray’s ePM 10M monitor is the inspired result of cutting-edge innovation and exceptional efficiency, continuing the Passport legacy in monitoring. Experience the immediate and measurable benefits of the smartphone-like user interface that delivers 90% of all common monitoring functions with just 2 gestures. A single swipe enables clinicians to see patient data in large numerics mode then swipe again, and a mini-trend window provides an immediate view of critical patient data, smoothing workflow at point-of-care.
Features and Benefits
- 10" multi-gesture, capacitive touchscreen displays, featuring intuitive user interface
- 8 waveforms
- Integrated parameters include 3/5-lead ECG, Nellcor OxiMax SpO2, NIBP, respiration, temperature
- Arrhythmia analysis with atrial fibrillation (Afib) detection standard
- Extensive data storage capability for trend data, alarms, events, and 48 hours of full disclosure
- Integrated HL7 and DIAP communication protocol for interface to EMR
- Parameter list tile with automatic highlight of abnormal readings
- One touch to drag icon tab right and instantly view mini-trend screen or set baseline vitals at the start of a patient case
- Manufactured with industry-leading plastics that stand up to the most stringent medical grade cleaners
- IP44 rated, resistant to damage often caused by continuous cleaning and usage
- Expanding extension rack supports plug-and-play parameter modules
- The concealed grab-and-go handle eliminates hard to clean crevices and eases clinical workflow while on the move
- Optional CO2 Sidestream and Microstream available
Materials Included
- ePM 10M Patient Monitor
- (1) Lithium Ion Battery
- (1) Adult Reusable Cuff
- (1) 3.5m NIBP hose
- (1) Power Cord
- (1) Paper Roll
- (1) ECG Trunk Cable
- (1) 3-Lead Adult/Pediatric Snap Wire Set
- (1) Nellcor Adult Reusable Sensor
- (1) Nellcor Sensor Cable
- (1) Temperature Probe Adapter Cable
- User Manual
Note: Temperature probes are sold separately.
Technical Specifications
- Weight: 8.8 lbs
- Size: 10.6" x 9.9" x 6.3"
- Power Requirements
- Line Voltage: 100 to 240 VAC (±10 %)
- Maximum Current: 2.0 A
- Frequency: 50/60 Hz (±3 Hz)
- Battery: Rechargeable lithium-ion battery, 4500mAh ≥ 4 hours run time
- Environmental Requirements
- Temperature
- Operating
- 0 to 40 °C (without AG and CO2 module)
- 10 to 40 °C (with AG and CO2 module)
- Storage: -20 to 60 °C
- Operating
- Humidity
- Operating: 15 to 95 % (non condensing)
- Storage: 10 to 95 % (non condensing)
- Barometric
- Operating: 427.5 to 805.5 mmHg (57.0 to 107.4 kPa without AG and CO2 module)
- Storage: 120 to 805.5 mmHg (16.0 to 107.4 kPa without AG and CO2 module)
- Temperature
- Interfacing
- Main Unit
- AC power connector (1)
- VGA port (1)
- USB 2.0 connector (2)
- Analog output/nurse call/defib. Sync/Serial Port (1)
- Integrated module rack (1), for 2 slots
- Main Unit
- Barcode Scanner: Supports 1D and 2D barcode (Barcode is not included)
- Thermal Recorder: 3 traces (paper 50 mm width, 20 m length)
- Network Printer: Support
