The Accutorr 3 is a compact, lightweight portable vital signs monitor ideal for the low acuity areas of your hospital. It is easy to transport from bed to bed, whether by its integrated handle or a compact rolling stand. With its touchpad user interface it is also simple to use. The Accutorr 3 offers a standard RS-232 interface that allows for the direct export of vital signs data into an Electronic Medical Record (EMR).
Features and Benefits
- High definition LCD provides clear view of patient data
- Highly mobile vital signs solution weighing 4 lbs (1.9 kg)
- All functions accessible through four button touchpad
- Standard parameters include NIBP and pulse rate
- Available SpO2 technology includes Masimo SET® (standard) or Nellcor® OxiMax®
- Optional Mindray SmarTemp® or Welch Allyn® SureTemp® Plus temperature
- PI (Perfusion Index) provides indication of SpO2 measurement reliability
- Comfortable carrying handle
- Li-ion battery provides up to 22 hours of continuous use
- Four button user interface allows simple navigation through all Accutorr 3's parameters and settings
- Easy selection of adult, pediatric and neonatal patient size settings
- Standard RS-232 communication supports connections to the Accutorr CS Charting Solution software and other EMR solutions
- Mounting options include an easy-to-maneuver rolling stand and wall mounts with quick release mounting brackets
Materials Included
- Accutorr 3 Unit
- (1) Adult Cuff
- (1) Roll of Paper
- (1) NIBP Hose
- (1) Line Cord
- (1) Nellcor SpO2 Adult Reusable Sensor
- (1) Nellcor SpO2 Cable
- User Manual
Note: This product comes with AC power plug, battery is sold separately.
Technical Specifications
- Interfacing
- Connectors: Serial port for software upgrade and DIAP protocol
- Battery
- Type: Rechargeable lithium ion
- Run Time:
- Up to 22 hours when powered by a new fully-charged battery at 77°F±41°F (25°C±5°C) with SpO2 and NIBP measurements at an interval of 15 minutes
- Charge Time:
- Monitor Power Off
- Less than 5.5 hours to 90%
- Less than 6.5 hours to 100%
- Monitor Power On
- Less than 10.5 hours to 90%
- Less than 11.5 hours to 100%
- Monitor Power Off
- Physical Dimensions
- Monitor Size:
- 9.62" x 4.7" x 5.3"
- 24.4 cm x 11.9 cm x 13.5 cm
- Monitor Weight: <4.2 lbs (<1.9 kg) including battery
- Monitor Size:
- Environmental Conditions
- Operating Temperature: 0°C to 40°C (SmarTemp™: 5°C to 40°C)
- Operating Humidity: 15% to 95%, non-condensing
- Baromatric: 427.5 to 805.5 mmHg (57.0 to107.4 kPa)
- Power Requirements: 100 to 240 VAC, 0.9 to 0.5 A, 50/60 Hz
- Safety Type of Protection: Meets the requirements of IEC 60601series
Warranty Information
- 1-Year Warranty
