The MicroCap 9 handheld Capnograph and Oximeter is capable of severe monitoring conditions, providing reliable Sp02 and pulse rate measurements.
Features
- 2.8 inch TFT, monitoring EtC02/C02, RR and Sp02, PR
- Temperature, Pressure compensation system and Zero readjustment system
- Balance gas compensation minimizing infl uence against other gases
- Lung pressure and temperature compensation (BTPS compensation) avaiable
- Applicable for intubated or non-intubated patients
- Pump flux for adult and infant
- Water filter specially designed for heavy humid environment
- Audio and Visual alarm for exceeding limits and Apnea
- 24 hours graphic trend can be stored after power-off
- Nellcor Sp02 optional
- USB Connectivity to PC for data transfer
- Accurate monitoring even with weak pulse signals.
- Reliable monitoring in motional situation.
Provides graphical trends and plethysmographic waveform
Specifications
- EtC02/C02
- EtC02/C02 range: 0 -150mmHg(0-20kPa,or 0-20%(V/V))
- Accuracy: ±2mmHg when 0-40mmHg ±5%(reading) when> 41-70mmHg ±8%(reading) when > 71-100mmHg ±10%(reading) when> 101-150mmHg
- Update: Every breath, 10sec, 20sec or 30sec selectable
- Trend length: 24 hours
- RESPIRATION RATE
- Range: 3-150t/min
- Accuracy: ±1 %(reading) or ±1 times/min whichever is greater
- Trend length: 24 hours
- Flux: 50-250cc/min selectable
- SpO2
- Oximetry saturation range: 0-100%
- Accuracy: ±2% when 70-100% ±3% when 50-69%
- Trend length: 24 hours
- PULSE RATE
- Range: 30-250 bpm
- Accuracy: ±2bpm or ±2%(reading) when 30-250bpm
- Trend length: 24 hours
- POWER
- AC input: 100V-250V, 50Hz/60Hz
- AC power consumption: 5W
- OPERATION
- Working temperature: 5-40 ºC
- Humidity: 30 – 75% (non-condensing)
- Atmospheric pressure: 86 – 106kPa
- BATTERY
- Battery type: Built-in rechargeable lithium battery
- Battery capacity: 3.6V, 3000mAh
- Working time: 10 hours
- PHYSICAL DATA
- Dimension: 70mm(W) x 160mm(H) x 40mm(D)
- Weight: 600grams
- LANGUAGE
- English/ Spanish/ Dutch
