| HPIS Code | 390_50_0_0 |
| Latex Free | Yes |
| UNSPSC | 42161610 |
Preconnected Hemofilter Sets with the AN 69 Dialyzer Membrane for CRRT.
The PRISMAFLEX Set is indicated for use only with the PRISMAFLEX Control Unit in providing continuous fluid management and renal replacement therapies. The system is intended for patients who have acute renal failure, fluid overload, or both.
This set is intended for use in the following veno-venous therapies: SCUF; CVVH; CVVHD; CVVHDF.
The PRISMAFLEX M100 & M150 Sets should be restricted to patients with a body weight greater than 30 kg (66 lb). The pediatric use of the PRISMAFLEX M60 Set should be restricted to children with a body weight greater than 11 kg (24 lb) with respect to extracorporeal blood volume.
Materials
• AN 69 HF hollow fiber: Acrylonitrile and sodium methallyl sulfonate copolymer
• Filter housing and headers: Polycarbonate
• Filter potting compound: Polyurethane
• Tubing material: plasticized polyvinyl chloride (PVC)
• Cartridge: PETG
• Sterilization mode: EtO (ethylene oxide)
• Not made with natural rubber latex
• Contains DEHP, which may pose risks to infant development
Filter operating specifications
• Maximum TMP* (mmHg/kPa): 450/60
• Maximum blood pressure (mmHg/kPa): 500/66.6
• Minimum blood flow rate:
PRISMAFLEX M60 Set: 50 ml/min
PRISMAFLEX M100 Set: 75 ml/min
PRISMAFLEX M150 Set: 100 ml/min
Filter data
• Nominal physical characteristics
- Effective surface area:
PRISMAFLEX M60 Set: 0.6 m²
PRISMAFLEX M100 Set: 0.9 m²
PRISMAFLEX M150 Set: 1.5 m²
- Fiber internal diameter (wet): 240 µm
- Fiber wall thickness: 50 µm
Sieving coefficient
• (bovine plasma, Pc 60 g/l, T = 37°C)
Urea = 1, Creatinine = 1, Vitamin B12 = 1,
Inulin = 0.95, Myoglobin = 0.55, Albumin <0.01
