Delta 1600 AED tester is exclusively designed to test all automated External Defibrillators, including Pulsed AEDs (Schiller).
Routine AED testing ensures that the device is working accurately according to the specifications of the AED manufacturers.
Dedicated function keys and a menu-driven display makes this device exceedingly intuitive to use. Its built-in load resistance of 50 ohms also replicates the impedance of the human body, ultimately providing you with realistic simulations.
Delta 1600 is compact, battery operated and ideally suited for testing all automated and semi-automated AEDs in the field.
FEATURES
- Compact, lightweight and easy-to-use
- Auto Function – Eliminates multiple discharges
- Large backlit graphics display
- Multiple arrhythmia simulations
- 7.4 Volt Li-Ion rechargeable battery
- Includes a complete set of insulated banana jacks and a soft carrying case
- 5 Year Warranty
Energy Output:
|
Maximum Energy: |
500 J |
|
Display Resolution: |
Based on Auto Range |
|
Resolution: |
1 J |
|
Accuracy: |
±1 % of reading ± 1 |
Load Resistance:
|
50 ohms ±1 %; non-inductive (< 1 μH) |
|
|
Sampling Time: |
20 uS |
|
Measurement Time Window: |
60 ms |
|
Pulse Width: |
60 ms |
Patient Simulator:
|
Waveform Simulation: |
ECG (NSR),ECG Rate: 60, 70, 80, 90, 100, 110, 120, 130, 140, 150, 160, 170, 180, 190, 200, 220, 240. BPM |
|
Accuracy: |
± 1% |
|
Waveform Amplitude: |
ECG (AMP) |
|
ECG Amplitude: |
1.0, 2.0, 3.0, 4.0 mV |
|
Accuracy: |
± 5% peak to peak |
Arrhythmia Selections: (Shock advisory waveforms)
|
Ventricular Fibrillation Coarse (VFBC) |
|
Ventricular Fibrillation Fine (VFBF) |
|
Ventricular Tachycardia (VTAC) |
|
Atrial Fibrillation (AFIB) |
Temperature Range:
|
Operating: |
+15°C to +35°C |
|
Storage: |
0°C to +50°C. |
Display:
|
Type: |
LCD with LED backlit Graphics display |
Power:
|
7.4 Volt Li-Ion Rechargeable Battery |
|
100-230 VAC input 8.5V Battery Charger |
Housing:
|
High impact ABS plastic enclosure |
Dimensions:
|
D x W x H :10.25 x 6.25 x 2.5 Inch |
