Expanding upon the features of the DUS6, the DUS60 combines an excellent value with superior quality across a variety of clinical applications. Suitable for MSK, abdomen, OB, GYN, Urology, Small parts and biopsy exams, the DUS60 utilizes PW imaging to meet increasing diagnostic needs.
- Multi-purpose for MSK, abdomen, OB, GYN, Urology, Small parts and biopsy.
- Digital Beam former.
- Two transducer connectors.
- Multi-frequency transducer series, fulfill different applications.
- Maximum frequency up to 10MHz10 inches non-interlaced monitor.
- USB ports support storage, transferring and printing.
- THI (Tissue Harmonic Imaging)
- TSI (Tissue Specific Imaging)
- DUS 60 - Digital Ultrasound Diagnostic System
- 10 inch non-interlaced monitor
- Two standard transducer connectors
- 8-segment TGC control
- IP(Image Processing) function
- 256-frame cine loop memory
- 56MB image storage capacity
- Two USB ports(1 host, 1 device)
- Measurement & Calculation software package
- Flash Disk
Available Transducers
| Transducers |
| Convex array transducer C361-2 (2.5/3.5/4.5/H2.5/H2.7) |
| Linear array transducer L743-2 (6.5/7.5/8.5/H4.5/H4.7) |
| Linear array transducer L761-2 (6.5/7.5/8.5/H4.5/H4.7) |
| Micro-convex array transducer C611-2 (5.5/6.5/7.5/H4.5/H4.7) |
| Transvaginal transducer E611-2 (5.5/6.5/7.5/H4.5/H4.7) |
| Endorectal transducer E741-2 (6.5/7.5/8.5/H4.5/H4.7) |
- Needle guide bracket for transducers
- Video Printer
- DICOM 3.0 software package
- Mobile Trolley
- Carrying bag
- Footswitch
- Imaging Mode: B, B+B, 4B, B+M, M, PW
- Display: 12.1" TFT-LCD
- Transducer Frequency: 2.0-10.0 MHZ
- Transducer Connector: 2 Standard
- Scanning Angle: 30 to 155 degree (depending on transducers)
- Scanning depth (mm): 20 to 250 (depending on transducers)
- Cine Loop: 256 frames bi-directional cine-loop
- Zoom: x1.0, x1.2, x1.4, x1.6, x2.0, x2.4, x3.0, x4.0 in distance
- Body Mark: >130 types
- Battery Life: 12 hours
- Dimensions: 330mm(L) x 320mm(H) x 220mm(W)
- Weight: 7.1kg
- 2-Year Warranty
